Configuration Examples
Configuration Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-CONFIG/EGB, Rev. A, 2013-04-03,
Autronica Fire and Security AS
Page 117
9. Configuration Examples
9.1 Before you Start
Autroprime is provided to the user in a pre-configured state, in this
state the panel is set to recognize detectors and other loop units
connected to the detection loops and the availability of routing
equipment, etc.
To simplify the understanding of the configuration principles, the first
example (1) deals with 1 loop and 8 points only.
The default setup provides the following:
Loop Units/Points: All loop units, including; detectors, manual
call points (points), electronic sounders and I/O units, are
automatically assigned addresses (sequencially numbered)
starting with address A1001, followed by address A1002, A1003
and so on. The addresses are used as names in the configuration
menu.
Detection Zones and Alarm Zones: By default the system has
one Detection Zone and one Alarm Zone.
Activation of Outputs: A point in alarm will activate all Fire
Alarm Devices and Fire Alarm Routing Equipment.
Detection Zone Type: All detection zones are defined as
Immediate Action Detection Zones.
Based on this default configuration, a site-specific configuration can
be carried out. The examples (example 1 and 2) in this chapter
deals with a site-specific configuration of a typical medium-sized
installation.
