Configuration Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-CONFIG/EGB, Rev. A, 2013-04-03,
Autronica Fire and Security AS
Page 131
9.3.4 Step 2: Connect Fire Alarm Devices to new alarm zones (5.5.3)
One FAD (the sounder outside CORRIDOR SOUTH in the
example) is to be connected to Alarm Zone 1 and another FAD (the
sounder outside the STORAGE) is to be connected to Alarm Zone 2.
In this example, the Default Alarm Zone is to be defined as the
Parent Alarm Zone for both Alarm Zone 1 and Alarm Zone 2.
From the Service Menu, perform the following:
 Use the arrow down button to scroll downwards to
Unit Configuration, then press Enter.
 Use the arrow down button to scroll downwards to Fire Alarm
Devices.
 Use the arrow up/down button to select the first FAD (the sounder
in Alarm Zone 1), then press the Function button
 Select Move to Alarm Zone (the first menu selection), then press
Enter.
 Select Create New Alarm Zone (the first menu selection), then
press Enter twice.
 Type the name of the new Alarm Zone, for example Alarm Zone
1,
then press Enter.

 The cursor will move to the line below: Parent Alarm Zone. In this
example the Default Alarm Zone is the Parent Alarm Zone.

 Press Enter to select Default Alarm Zone.
 Press Enter to confirm the settings (Accept).
 In the Fire Alarm Devices menu, select the second FAD (the
sounder in Alarm Zone 2) and repeat the entire procedure
described above (create Alarm Zone 2 and connect the second
FAD to this alarm zone, then select the Default Alarm Zone as the
Parent Alarm Zone).
9.3.5 Step 3: Connect already configured detection zones to a new alarm
zone (Alarm Zone 1). (5.2.3)
The detection zones, DZ1, DZ2, DZ3 and DZ4 have to be connected
to the new Alarm Zone 1.
From the Detection Zone Menus (5.2.1), perform the following:
 Press and hold down the Select button
to mark all four
detection zones (DZ1, DZ2, DZ3 and DZ4), then press the
Function button
 Select Connect to Alarm Zone (the first menu selection),
then press Enter.
 Use the arrow down button to select Alarm Zone 1.
 Press Enter to connect the detection zones to this alarm
zone.
 To confirm the setting, press Enter once more.


