Autronica Autroprime 2 User Manual

Configuration Examples
Configuration Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-CONFIG/EGB, Rev. A, 2013-04-03,
Autronica Fire and Security AS
Page 128
9.3.1 Site-specific Configuration – Example 2
Step 1: Create the new detection zones and connect the points (loop
units) to the new detection zones (5.4.3)
All new points in the Storage/Workshop building have to be
connected to the new detection zones, DZ5, DZ6 and DZ7. Note that
the electronic sounders (Fire Alarm Devices, FADs) in this example
are not to be connected to detection zones.
 Add a site-specific name to each new address (point) if needed
(9.2.7/ 5.4.2).
 Step 2: Connect Fire Alarm Devices to new alarm zones
(5.5.3)
One FAD is to be connected to Alarm Zone 1 and another FAD is
to be connected to Alarm Zone 2.
 Step 3: Connect already configured detection zones to a new
alarm zone (Alarm Zone 1). (5.2.3)
The detection zones, DZ1, DZ2, DZ3 and DZ4 have to be
connected to the new Alarm Zone 1.
 Step 4: Connect the new detection zones to a new alarm zone
(Alarm Zone 2). (5.2.3)
The new detection zones, DZ5, DZ6 and DZ7 have to be
connected to the new Alarm Zone 2.
 Step 5: Define Alarm Zone 1 and Alarm Zone 2 as Neighbour
Alarm Zones (5.3.3)
 Step 6: Connect a point in Detection Zone 6 to the Parent
Alarm Zone (5.2.3)
A manual activation of the manual call point in Detection Zone 6 is
to be configured to activate all Fire Alarm Devices belonging to
Alarm Zone 1 and 2 (Parent Alarm Zone).
 Step 7: Configure outputs for ventilation control and door control
(5.4.4 and 5.2.4)
 Step 8: Save the configuration and restart the system
When the additional configuration is completed, you have to save
the new configuration and restart the system (9.2.4/3.2/3.3).
 In this example, all points activate outputs to Fire Alarm Devices
(FAD), Fault Warning Routing Equipment (FWRE) and Fire Alarm
Routing Equipment (FARE). As this specific functionality already
is provided by the default configuration, no configuration is
required.
Refer to chapter 5.2.4, 5.4.4 and 5.6.
Configuration Example 2 is based on the steps that are already
performed in Configuration Example 1. The following steps cover
the configuration that has to be added/changed in order to complete
Configuration Example 2.

