Unit Configuration
Configuration Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-CONFIG/EGB, Rev. A, 2013-04-03,
Autronica Fire and Security AS
Page 63
5.7.3 Connect to Output
This menu allows you to connect a selected local output to an
output. The menu selection applies to open collector 1 and 2.
Note that the menu selection does not apply to Fire Alarm Devices
(FAD), Fire Alarm Routing Equipment (FARE) and Fire Warning
Routing Equipment (FWRE).
From the Local Outputs Menu (5.7.1), perform the following:
After pressing the Function button for the selected Local
Output(s), select Connect to Output (the first menu selection),
then press Enter.
A list of all available outputs will appear in the display.
Use the arrow up/down button to select the output that
is to be connected to the selected local output, then press Enter.
To confirm the setting, press Enter once more.
5.7.4 Connect to Activation Group
This menu allows you to connect a selected local output to an
Activation Group. The menu selection applies to open collector 1
and 2.
Note that the menu selection does not apply to Fire Alarm Devices
(FAD), Fire Alarm Routing Equipment (FARE) and Fire Warning
Routing Equipment (FWRE).
From the Local Outputs Menu (5.7.1), perform the following:
After pressing the Function button for the selected Local
Output(s), use the arrow down button to scroll downwards to
Connect to Activation Group, then press Enter.
A list of all available activation groups will appear in the display.
Use the arrow up/down button to select the activation group that
is to be connected to the local output, then press Enter.
To confirm the setting, press Enter once more.
