Unit Configuration
Configuration Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-CONFIG/EGB, Rev. A, 2013-04-03,
Autronica Fire and Security AS
Page 56
5.6.3 Connect to Output
This menu allows you to determine, for a selected loop output, which
outputs that are to be activated on the activation of this loop output.
In the example below, loop output 1 will on activation, activate output
2 and 3.
Note that the menu selection does not apply to Fire Alarm Devices
(FAD), Fire Alarm Routing Equipment (FARE) and Fire Warning
Routing Equipment (FWRE).
From the Loop Outputs Menu (5.6.1), perform the following:
After pressing the Function button for the selected Loop
Output(s), select Connect to Output (the first menu selection),
then press Enter.
A list of all available outputs will appear in the display.
Use the arrow up/down button to select the output(s) that
is to be activated on the activation of the loop output, then press
Enter.
To confirm the setting, press Enter once more.
5.6.4 Connect to Activation Group
This menu allows you to connect a selected loop output to an
Activation Group by which it will be activated.
Note that the menu selection does not apply to Fire Alarm Devices
(FAD), Fire Alarm Routing Equipment (FARE) and Fire Warning
Routing Equipment (FWRE).
From the Loop Outputs Menu (5.6.1), perform the following:
After pressing the Function button for the selected Loop
Output(s), use the arrow down button to scroll downwards to
Connect to Activation Group, then press Enter.
A list of all available activation groups will appear in the display.
Use the arrow up/down button to select the activation group that
is to be connected to the loop output, then press Enter.
To confirm the setting, press Enter once more.
Loop
Output 1
Output 3
Output 2
