System Settings
Configuration Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-CONFIG/EGB, Rev. A, 2013-04-03,
Autronica Fire and Security AS
Page 20
3.8 Sound Patterns
The standard setup of the system provides the following default
sound patterns in the following prioritized order:
Sound signal Default sound patterns Default Prolong Signal (the
last bit)
Custom-defined Pattern 1 0000000000000000 0 seconds
General Alarm Pattern 0101010101010101 2 seconds
Evacuate Pattern 1100110011001100 0 seconds
Alert Pattern 1000000010000000 0 seconds
Custom-defined Pattern 2 0000000000000000 0 seconds
Custom-defined Pattern 3 0000000000000000 0 seconds
Pattern Activation
Detection zones are connected to alarm zones (Main Alarm Zones).
An alarm signal from the detection zones activates the EVACUATE
pattern in these alarm zones. Neighbour Alarm zones may be
connected to the Main Alarm Zones. The Neighbour Alarm Zones
will have the ALERT pattern activated.
The remaining patterns may be activated from an input signal
configured as “Activate all Alarms” (refer to 5.9.2). Be aware of the
priority given in the table above.
The following settings are available for each sound pattern:
The Sound Pattern is set by choosing a predefined 16 bit number
(binary) which determines the pattern (for example, the Alert Pattern,
including the following bits; 1000000010000000). The one-digits
correspond to ON, and the zero-digits correspond to OFF.
Prolong Signal: It is possible to prolong the last signal (i.e. the last
bit) for a chosen sound pattern from 1 to a maximum of 99 seconds.
Sound Level: It is possible to choose between High, Medium or Low
sound level. (Not applicable for BBL-100 and BBL-100/IP).
Sound Tone: It is possible to choose between Continuous or Slow
Whoop. (Not applicable for BBL-100 and BBL-100/IP).
