Unit Configuration
Configuration Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-CONFIG/EGB, Rev. A, 2013-04-03,
Autronica Fire and Security AS
Page 57
5.6.5 Disconnect from Output
This menu allows you to disconnect a selected loop output from an
output, meaning that the selected loop output will, on activation, not
activate the output. In the example below, loop output 1 will on
activation, no longer activate output 3 (only output 2).
Note that the menu selection does not apply to Fire Alarm Devices
(FAD), Fire Alarm Routing Equipment (FARE) and Fire Warning
Routing Equipment (FWRE).
From the Loop Outputs Menu (5.6.1), perform the following:
After pressing the Function button for the selected Loop
Output(s), use the arrow down button to scroll downwards to
Disconnect from Output, then press Enter.
In the display you will now see a list of all outputs that are connected
to the selected loop output.
To disconnect the selected loop output from an output, use the
arrow down button to select the output, then press
Enter.
To confirm the setting, press Enter once more.
5.6.6 Disconnect from Activation Group
This menu allows you to disconnect a selected loop output from an
Activation Group.
Note that the menu selection does not apply to Fire Alarm Devices
(FAD), Fire Alarm Routing Equipment (FARE) and Fire Warning
Routing Equipment (FWRE).
From the Loop Outputs Menu (5.6.1), perform the following:
After pressing the Function button for the selected Loop
Output(s), use the arrow down button to scroll downwards to
Disconnect from Activation Group, then press Enter.
In the display you will now see a list of all activation groups that are
connected to the selected loop output.
To disconnect the selected loop output from an activation group,
use the arrow down button to select the activation group, then
press Enter.
To confirm the setting, press Enter once more.
Loop
Out
