Unit Configuration
Configuration Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-CONFIG/EGB, Rev. A, 2013-04-03,
Autronica Fire and Security AS
Page 65
5.7.7 Show Activating Detection Zones
This menu allows you to view all detection zones that are connected
to the selected local output. The menu selection applies to onboard
General Outputs only.
Note that the menu selection does not apply to Fire Alarm Devices
(FAD), Fire Alarm Routing Equipment (FARE) and Fire Warning
Routing Equipment (FWRE).
From the Local Outputs Menu (5.7.1), perform the following:
After pressing the Function button for the selected Local
Output(s), use the arrow down button to scroll downwards to
Show Activating Detection Zones, then press Enter.
In the display you will now see a list of all detection zones that are
connected to the selected local output.
Use the arrow up/down button to select a detection zone, then
press Enter.
The name of the detection zone and unit function will appear in the
display.
5.7.8 Show Activating Points
This menu allows you to view all points that are connected to the
selected local output. The menu selection applies to onboard
General Outputs only.
Note that the menu selection does not apply to Fire Alarm Devices
(FAD), Fire Alarm Routing Equipment (FARE) and Fire Warning
Routing Equipment (FWRE).
From the Local Outputs Menu (5.7.1), perform the following:
After pressing the Function button for the selected Local
Output(s), use the arrow down button to scroll downwards to
Show Activating Points, then press Enter.
In the display you will now see a list of all points that are connected
to the selected local output.
Use the arrow up/down button to select a point, then press Enter.
The point’s properties will appear in the display.
