Unit Configuration
Configuration Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-CONFIG/EGB, Rev. A, 2013-04-03,
Autronica Fire and Security AS
Page 62
5.7.2 Configure Properties for a Local Output
The following properties can be changed:
 the name of the local output
 the “unit function” for a local output – applies only to the standard
outputs on the main board’s terminal block J1.

Terminal Output hardware type Default function
J1.12 Monitored Output 1 +24V FAD 1
J1.13 Monitored Output 1 0V FAD 1
J1.14 Monitored Output 2 +24V FAD 2
J1.15 Monitored Output 2 0V FAD 2
J1.16 Open Collector Output 1 General Output 1
J1.17 Open Collector Output 2 General Output 2
J1.18 Auxiliary +24V Out Intended used for Open collector
J1.19 Relay Output 1 Com
FARE
J1.20 Relay Output 1 NO
J1.21 Relay Output 1 NC
J1.22 Relay Output 2 Com
FWRE
J1.23 Relay Output 2 NO
J1.24 Relay Output 2 NC
From the Local Outputs Menu (5.7.1), perform the following:
 After selecting the Local Output in question by means of the
arrow down/up buttons, press Enter twice.
 Type a new Name, or accept the existing one by pressing the
arrow down button.
 Press Enter, then use the arrow left/right arrow buttons to select
among the following unit functions:
o Fire Alarm Device:
equipment giving warning of fire, for example, a sounder or visual
indicator.
o Disable Out:
output that is activated when there are disablements in the
system
o General Output:
output that is activated according to the configured events, for
example, Pre Alarm, Alarm, Input Activated etc.
o RESET Out:
output activated for approx. 2 seconds when the Reset button
is operated.
o Silent Alarm Output:
output dedicated to be activated at Silent Alarm regardless of alarm
origin
o Silence Out:
output activated for approx. 2 seconds when the Silence button is
operated
o Small Alarm Output:
output dedicated to be activated at Small Alarm regardless of alarm
origin
o Fire Alarm Routing Equipment (FARE):
equipment routing an alarm signal from control and indicating
equipment to a Fire Alarm Receiving Station.
o Fault Warning Routing Equipment (FWRE):
equipment routing a fault warning signal from control and indicating
equipment to a fault warning receiving station.
 Press Enter.
 To confirm the setting, press Enter once more.

