Unit Configuration
Configuration Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-CONFIG/EGB, Rev. A, 2013-04-03,
Autronica Fire and Security AS
Page 45
5.4.2 Configure Properties for a Point
The following properties can be changed:
name of a point
override delay and dependency
In an alarm situation, the actioning of outputs will be delayed
when; the detection zone has been defined as a Delayed Action
detection zone (configurable) and the point(s) in this Delayed
Action detection zone has not been set to Override Delay and
Dependency, i.e. set to No.
performance class day setting (Normal 1, Normal 2; Industrial);
depends on the type of detector
operation class day setting (depends on the type of point;
MultiSensor with heat, MultiSensor only, Heat only)
performance class night setting (Normal 1, Normal 2; Industrial)
operation class night setting (MultiSensor with heat, MultiSensor
only, Heat only)
From the Points Menu (5.4.1), perform the following:
After selecting the point in question by means of the arrow
down/up buttons, press Enter twice.
Type a new Name then press Enter, or accept the existing one by
pressing the arrow down button.
Use the left or right arrow button to select Yes or No (Override
Delay and Dependency or not), then press Enter.
Use the left or right arrow button to select the desired
performance class day setting, then press Enter.
Use the left or right arrow button to select the desired
operation class day setting, then press Enter.
Use the left or right arrow button to select the desired
performance class night setting, then press Enter.
Use the left or right arrow button to select the desired
operation class night setting, then press Enter.
To confirm the setting, press Enter once more.
