Unit Configuration
Configuration Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-CONFIG/EGB, Rev. A, 2013-04-03,
Autronica Fire and Security AS
Page 66
5.7.9 Show Activating Inputs
This menu allows you to view all inputs that are connected to the
selected local output. The menu selection applies to onboard
General Outputs only.
Note that the menu selection does not apply to Fire Alarm Devices
(FAD), Fire Alarm Routing Equipment (FARE) and Fire Warning
Routing Equipment (FWRE).
From the Local Outputs Menu (5.7.1), perform the following:
After pressing the Function button for the selected Local
Output(s), use the arrow down button to scroll downwards to
Show Inputs, then press Enter.
In the display you will now see a list of all inputs that are connected
to the selected local output.
Use the arrow up/down button to select an input, then press
Enter.
The input’s properties will appear in the display.
5.7.10 Show Activating Groups
This menu allows you to view all activation groups (groups; meaning
“Activation Groups”) that are connected to the selected local output.
The menu selection applies to onboard General Outputs only.
Note that the menu selection does not apply to Fire Alarm Devices
(FAD), Fire Alarm Routing Equipment (FARE) and Fire Warning
Routing Equipment (FWRE).
From the Local Outputs Menu (5.7.1), perform the following:
After pressing the Function button for the selected Local
Output(s), use the arrow down button to scroll downwards to
Show Activation Groups, then press Enter.
In the display you will now see a list of all activation groups that are
connected to the selected local output.
Use the arrow up/down button to select the Activation Group,
then press Enter.
The following information will appear in the display (for information
on unit state and coincidence, refer to chapter 5.4.4):
o the name of the Activation Group
o the Unit State
o the Coincidence
