Unit Configuration
Configuration Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-CONFIG/EGB, Rev. A, 2013-04-03,
Autronica Fire and Security AS
Page 42
5.3.4 Disconnect from Neighbour Alarm Zone
This menu allows you to disconnect neighbourhood relations
between alarm zones.
From the Alarm Zones Menu (5.3.1), perform the following:
After pressing the Function button for the selected alarm zone(s),
use the arrow down button to select Disconnect Neighbour
Alarm Zone, then press Enter.
A list will appear, listing all alarm zones that have neighbourhood
relations.
Select the alarm zone that is to be disconnected, then press
Enter.
To confirm the setting, press Enter once more.
5.3.5 Show Member Fire Alarm Devices
This menu allows you to view all Fire Alarm Devices (FADs)
belonging to an alarm zone.
From the Alarm Zones Menu (5.3.1), perform the following:
After pressing the Function button for the selected alarm zone(s),
use the arrow down button to select Show Member Fire Alarm
Devices, then press Enter.
A list of all Fire Alarm Devices (FADs) will appear in the display.
Use the arrow down button to select the FAD in question, then
press Enter.
The name of the FAD and the unit function will appear in the display.
5.3.6 Show Neighbour Alarm Zones
This menu allows you to view the neighbour alarm zones for a
selected alarm zone.
From the Alarm Zones Menu (5.3.1), perform the following:
After pressing the Function button for the selected alarm zone(s),
use the arrow down button to select Show Neighbour Alarm
Zones, then press Enter.
A list of all Neighbour Alarm Zones will appear in the display.
Use the arrow down button to select the Neighbour Alarm Zone
in question, then press Enter.
The name of the Neighbour Alarm Zone and the unit function will
appear in the display.
