Unit Configuration
Configuration Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-CONFIG/EGB, Rev. A, 2013-04-03,
Autronica Fire and Security AS
Page 36
5.2.3 Connect to Alarm Zone
This menu allows you to connect a detection zone to an existing
alarm zone.
From the Detection Zones Menu (5.2.1), perform the following:
 After pressing the Function button for the selected detection
zone(s), select Connect to Alarm Zone (the first menu selection),
then press Enter.
 Use the arrow down button to select an existing alarm zone.
 Press Enter to connect the detection zone to this alarm
zone.
 To confirm the setting, press Enter once more.
5.2.4 Connect to Output
This menu allows you to connect a detection zone to an output.
From the Detection Zones Menu (5.2.1), perform the following:
 After pressing the Function button for the selected detection
zone(s), use the arrow down button to select Connect to Output,
then press Enter.
Only local outputs of the type General Output will be listed.
 Use the arrow down button to select the output, then press Enter
twice.
 Use the arrow left/right buttons to select the Detection Activation
State (Prealarm, Small Alarm, Large Alarm, Silent Alarm), then
press Enter.
 To confirm the setting, press Enter once more.


