Unit Configuration
Configuration Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-CONFIG/EGB, Rev. A, 2013-04-03,
Autronica Fire and Security AS
Page 60
5.6.11 Show Activating Outputs
This menu allows you to view all outputs that are connected to the
selected loop output.
Note that the menu selection does not apply to Fire Alarm Devices
(FAD), Fire Alarm Routing Equipment (FARE) and Fire Warning
Routing Equipment (FWRE).
From the Loop Outputs Menu (5.6.1), perform the following:
 After pressing the Function button for the selected Loop
Output(s), use the arrow down button to scroll downwards to
Show Activating Outputs, then press Enter.
In the display you will now see a list of all outputs that are connected
to the selected loop output.
5.6.12 Show Connected Units
This menu allows you to view all connections that are connected to
the selected loop output (and that activate the selected loop output).
Note that the menu selection does not apply to Fire Alarm Routing
Equipment (FARE) and Fire Warning Routing Equipment (FWRE).
From the Loop Outputs Menu (5.6.1), perform the following:
 After pressing the Function button for the selected Loop
Output(s), use the arrow down button to scroll downwards to
Show Connections, then press Enter.
In the display you will now see a list of all connections that are
connected to the selected loop output.


