Autronica Autroprime 2 User Manual

Unit Configuration
Configuration Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-CONFIG/EGB, Rev. A, 2013-04-03,
Autronica Fire and Security AS
Page 86
5.12.4 Disconnect from Output
This menu allows you to disconnect a selected local input from an
existing Activation Group.
From the Activation Groups Menu (5.12.1), perform the
following:
 After pressing the Function button for the selected activation
group(s), use the arrow down button to scroll downwards to
Disconnect from Output, then press Enter.
In the display you will now see a list of all outputs that are connected
to the selected Activation Group.
 To disconnect the selected local input from an Activation Group,
use the arrow down button to select the output, then press
Enter.
 To confirm the setting, press Enter once more.
5.12.5 Show Member Points
This menu allows you to view all points that are connected to the
selected Activation Group.
From the Activation Groups Menu (5.12.1), perform the
following:
 After pressing the Function button for the selected activation
group(s), use the arrow down button to scroll downwards to
Show Connections, then press Enter.
In the display you will now see a list of all connections that are
connected to the selected Activation Group.
 Use the arrow up/down button to select a connection, then press
Enter.


