Serial port
IX14 User Guide
163
Configure UDP serial mode
The UDPserial mode option in the serial port configuration provides access to the serial port using
UDP.
To change the configuration to match the serial configuration of the device to which you want to
connect:
WebUI
1. Log into the IX14 WebUI as a user with Admin access.
2. On the menu, click System. Under Configuration, click Serial Configuration.
The Serial Configuration page is displayed.
Note You can also configure the serial port by using Device Configuration > Serial. Changes
made by using either Device Configuration or Serial Configuration will be reflected in both.
3. Click to expand the port that you want to configure for UDPserial mode.
The serial port is enabled by default. To disable, toggle off Enable.
4. For Mode, select UDP serial.
The default is Login.
5. (Optional) For Label, enter a label that will be used when referring to this port.
6. Expand Serial Settings.
