Port/connector Description
WAN/ETH1 See Connect the WAN/ETH1 port.
SERIAL1 See Connect the serial port and Serial port.
Power See Power on the IX14.
WWAN1-1
WWAN1-2
See Attach and position antennas.
IX14 power supply requirements
IX14 is intended to be powered by a certified power supply with output rated at either 12 VDC/0.75 A
or 24 VDC/0.375 A minimum.
n
If the IX14 is operated in an ambient temperature range from +0 C to +40 C, use the Digi power
supply accessory kits 76002078 or 76002080 to meet the temperature criteria.
n
If the IX14 is operated in an ambient temperature range from -34 C to +74 C, use the Digi power
supply accessory kits 76002079 or 76002081 to meet the temperature criteria.
n
If you are providing the DC power source with a non-Digi power supply, you must use a
certified LPS power supply rated at either 12 VDC/0.75 A or 24 VDC/0.375 A minimum. The
voltage tolerance supports +/- 10% (9 VDC to 30 VDC) at 9 Watts minimum.
IX14 LEDs
Power Solid blue
Initial power on as router prepares to boot up
Flashing blue
Router is booting up
Solid blue
Router bootup is complete when flashing stops
WWAN signal Off
SIMs are not in use
Solid red
Very Poor signal (-113 dBm to -99 dBm)
Solid orange
Poor signal (-98 dBm to -87 dBm)
Solid yellow
Fair signal (-86 dBm to -76 dBm)
