Routing IP routing
IX14 User Guide
706
Configure a static route
A static route is a manually configured routing entry. Information about the route is manually entered
rather than obtained from dynamic routing traffic.
Required configuration items
n
The destination address or network.
n
The interface to use to reach the destination.
Additional configuration items
n
A label used to identify this route.
n
The IPv4 address of the gateway used to reach the destination.
n
The metric for the route. When multiple routes are available to reach the same destination, the
route with the lowest metric is used.
n
The Maximum Transmission Units (MTU) of network packets using this route.
To configure a static route:
WebUI
1. Log into the IX14 WebUI as a user with full Admin access rights.
2. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
3. Click Network > Routes > Static routes.
