Services Modbus gateway

IX14 User Guide

403

where value is an integer from 0 to 255. Leave at the default setting of 0 to not adjust the

server address.

If a packet contains a Modbus server address above the amount entered here, the address

will be adjusted downward by this amount before the packet is delivered. This allows you

to configure clients on the gateway that will forward messages to remote devices with the

same Modbus address on different buses. For example, if there are two devices on two

different buses that have the same Modbus address of 10, you can create two clients on

the gateway:

Client one:

filter set to 10.

This will configure the gateway to deliver all messages that have the Modbus server

address of 10 to this device.

Client two:

filter set to 20.

adjust_server_address set to 10.

This will configure the gateway to deliver all messages that have the Modbus server

address address of 20 to the device with address 10.

i. Repeat the above instructions for additional clients.

6. Save the configuration and apply the change:

(config)> save

Configuration saved.

7. Type exit to exit the Admin CLI.

Depending on your device configuration, you may be presented with an Access selection

menu. Type quit to disconnect from the device.

Show Modbus gateway status and statistics

You can view status and statistics about location information from either the WebUI or the command

line.

WebUI

1. Log into the IX14 WebUI as a user with Admin access.

2. On the menu, select Status > Modbus Gateway.

The Modbus Gateway page appears.

Statistics related to the Modbus gateway server are displayed. If the message Server

connections not available is displayed, this indicates that there are no connected clients.

To view information about Modbus gateway clients, click Clients.

To view statistics that are common to both the clients and server, click Common

Statistics.

To view configuration details about the gateway, click the  (configuration) icon in the

upper right of the gateway's status pane.
