Page 7-14 Infinity Gamma Series VF4
Stored Recordings
The monitor can store up to 10 alarm or timed recordings consist-
ing of 20 seconds of data each (about 10 seconds of pre-event/
request data and about 10 seconds of post-event/request data.)
Recordings are stored when:
! No recorder/laser printer is available or if the recorder/laser
printer is temporarily out of order (i.e. no recording paper).
! You turned on the automatic storage of alarm recordings on
the Alarm Limits table (see the chapter Alarms and Mes-
sages).
When the recording storage is full, the monitor deletes the oldest
unsaved recordings as new recordings come in. You can view,
print, save, and delete stored recordings via the Event Recall
screen (see below).
Upon successfully storing a recording, the monitor emits 2 beeps.
To cancel a recording storage in progress, press the
Record fixed
key on the monitor within 5 seconds of the start of the recording
storage.
NOTE: The monitor does not store continuous, trend, OCRG or
diagnostic log recordings. Continuous recordings are converted to
timed recordings and then stored.
Event Recall
You can view 4 seconds of waveform data for each stored record-
ing on the Event Recall screen (4 seconds of pre-event/request
data). The screen also shows the parameter values at the time of
the recording storage.
To call up the Event Recall screen:
1. Press the
Menu fixed key.
2. Click on
Review.
3. Click on
Event Recall.
