Dräger Infinity Series User Manual

Page 16-10 Infinity Gamma Series VF4
Calibrating Reusable Transducers
You must calibrate reusable invasive blood pressure transducers
with the mercury manometer within five minutes after zeroing.
Note: This procedure is for reusable transducers only.
STEPS: Calibrating the IBP Transducer
1. Zero the pressure transducer via the IPB setup menu.
2. Click on the IBP1 parameter box.
3. Click on
Mano. Cal.
4. Connect the pressure transducer to the mercury manometer.
5. Pump the manometer to a value recommended by your hospi-
tal protocol.
6. Dial in the calibration value to match the mean pressure value
and click the knob.
7. If you are monitoring two invasive blood pressures, repeat
these steps for the second pressure parameter.
NOTE: If invasive blood pressure alarms are on, the message IBP
static appears.
