Chapter 4: Operation
4-16 Fresenius Medical Care multiFiltrate IFU-EN-UK 15A-2015
4.4.5 Selecting the treatment mode
When the treatment is continued with the
previous treatment parameters, the operator
has the option to start with or without using
the Reset balance data option.
 Use the rotary selector to select the
required function and press [OK].
Note
On the device, the current treatment mode is always displayed in the
upper left-hand corner of the screen in the status bar.
For technical reasons, the screens shown in the Instructions for Use do
not always represent the selected treatment mode.
Note
If citrate anticoagulation is activated, only the treatment modes CVVHD
and CVVHDF are available.
 Use the rotary selector to select the
required treatment mode and press [OK].
The paediatric treatment modes have to be
activated by the technician in the service
program.
Paed. CVVH
Paed. CVVHD
