GE RAFT VOLUSON™ P8/VOLUSON™P6

DIRECTION 5775469, R

EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL

3-54 Section 3-7 - Printer Installation

3-7-8-1 Report Printer Selection

1.) Click on the

PERIPHERALS tab.

(refer to:Figure 3-49: System Setup - Connectivity - PERIPHERALS page on page 3-48)

2.) Select the desired Report Printer from the pull-down menu.

NOTICE

!! NOTICE:

The selected Report Printer is usually used for printing reports and images from the Archive.
