GE RAFT VOLUSON™ P8/VOLUSON™P6

DIRECTION 5775469, R

EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL

8-50 Section 8-17 - Replacement of Keyboard Assembly-TOP

8.) Unscrew 2 screws and pick up the sub keyboard. Refer to the figures below.

8-17-4 Installation procedure

Install a new part in the reverse order of removal procedure.

Figure 8-63 Picking up the sub keyboard

Important Precautions3
