GE RAFT VOLUSON™ P8/VOLUSON™P6

DIRECTION 5775469, R

EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL

8-26 Section 8-9 - Replacement of ASSY BEZEL FRONT DVD PLASTIC BT16

Section 8-9

Replacement of ASSY BEZEL FRONT DVD PLASTIC BT16

8-9-1 Manpower

1 people, 1 minute

8-9-2 Tools

Not required

8-9-3 Disassembly Procedure

1.) Remove the ASSY BEZEL FRONT DVD PLASTIC BT16. Refer to the figure below.

8-9-4 Installation Procedure

Install the new parts in the reverse order of removal procedure.

Figure 8-22 Removing the ASSY BEZEL FRONT DVD PLASTIC BT16

ASSY BEZEL FRONT DVD

PLASTIC BT16
