GE RAFT VOLUSON™ P8/VOLUSON™P6
DIRECTION 5775469, R
EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL
3-56 Section 3-8 - System Configuration
3-8-1-1 To invoke the Setup procedure:
In general operations are done with the trackball and the trackball keys (mouse emulation).
1.) Press the F2
key on the control panel.
2.) In the “Utilities” menu select SYSTEM SETUP
to activate the setup desktop screen.
3.) Select the corresponding major group from the left side of the screen and then click the desired tab.
Trackball (mouse position):
positions the pointing device (arrow) on the desktop
left trackball key (left mouse button):
sets, fixates markers and activates pages/buttons etc. marked by the pointing device
upper trackball key (right mouse button):
no function in system desktop
right trackball key (left mouse button):
sets, fixates markers and activates pages/buttons etc. marked by the pointing device
