9-22 Section 9-12 - Probes

9-12-3 Real-Time 4D Volume Probes

Figure 9-11 Real-Time 4D Volume Probes

Table 9-14 Real-Time 4D Volume Probes

Item Part Name Part Number Description Qty CRU FRU

805

RIC5-9A-RS

KTZ304128

(H48701EJ)

Real-time 4D endocavity broadband electronic curved

array transducer 3.8 - 9.3 MHz, 192 Elements, field of

view: max. 180° Applications: Gynecology,

Obstetrics, Transrectal

-1 1

806

RAB2-6-RS

KTZ303982

(H48681WR)

Real-time 4D broadband electronic curved-array

transducer

2.0 - 5.0 MHz, 128 Elements Applications:

Abdominal, OB, Gyn

-1 1

806

805

* A green round label is attached on the RIC5-9A-RS (KTZ304128)
