GE RAFT VOLUSON™ P8/VOLUSON™P6

DIRECTION 5775469, R

EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL

8-100 Section 8-30 - Replacement of the Probe Holder(KIT)

Section 8-30

Replacement of the Probe Holder(KIT)

8-30-1 Manpower

One person, 1 minutes

8-30-2 Tools

None

8-30-3 Removal Procedure

1.) Remove 5 probe holders. Refer to the figure below.

8-30-4 Installation Procedure

1.) Install the new parts in the reverse order of removal.

Figure 8-147 Removing the 5 PROBE HOLDERs
