GE DRAFT VOLUSON™ P8/VOLUSON™P6

DIRECTION 5775469, R

EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL

Chapter 5 - Components and Functions (Theory) 5-35

5-6-2 OPIO layout

Figure 5-14 Voluson™ P8/Voluson™P6 - OPIO Layout

5-6-3 Button Description

1. Loudspeaker position

2. Menu window digipot

controls

3. TGC Slider controls

4. Trackball

5. Alphanumeric Keyboard

6. Probeholders

7. Menu window flip-

switch controls

8. Mode keys

(digipot controls)

9. Toggle switch controls

10. Hard keys

11. Trackball buttons
