GE DRAFT VOLUSON™ P8/VOLUSON™P6
DIRECTION 5775469, R
EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL
Chapter 5 - Components and Functions (Theory) 5-31
Table 5-5 Voluson™ P8/Voluson™P6 - DRFG components
5-4-1 Hard Disk Drive
The Hard Disk is the main storage device of the Voluson™ P8/Voluson™P6.
The Voluson™ P8/Voluson™P6 500 Gbyte Hard disk, which is controlled by the CPU via signals from
SATA, is divided into 4 partitions.
For further details see: Section 5-2-6 "Data Location" on page 5-24.
5-4-2 SOM (System On Module)
5-4-2-1 Congatec
SOM Module for VP6/VP8/VS8/VS10/VS10 Expert
- On Board HDMI, LAN, USB 2.0, Sound
- CPU: Intel
®
Core
TM
i3-6100E Processor, 2.7GHz
Major Tasks:
- System Control
- 2D- / 3D- / 4D- Image processing and Rendering
Sub-section Description Page Number
5-4-1
Hard Disk Drive
5-31
5-4-2
SOM (System On Module)
5-31
