GE RAFT VOLUSON™ P8/VOLUSON™P6

DIRECTION 5775469, R

EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL

8-138 Section 8-45 - Replacement of the DBM64G

2.) Unscrew 6 screws.

3.) Remove DBM64G from the EMI SHIELD BRACKET.

8-45-5 Installation Procedure

1.) Install the new parts in the reverse order of removal.

2.) Perform: FRU8-36: Replacement of the DBM64G - Functional Tests..

Figure 8-198 Unscrewing 6 screws and removing the EMI SHIELD BRACKET
