GE RAFT VOLUSON™ P8/VOLUSON™P6

DIRECTION 5775469, R

EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL

4-42 Section 4-7 - Peripheral Checks

4-7-3 Brakes and Direction (Swivel) Locks

Check the brakes and swivel locks function as described below.

Table 4-9 Brakes and Direction (Swivel) Lock

Step Task Expected Result(s)

Swivel lock engaged.

Brakes and swivel lock released.

Brakes and swivel lock engaged ( = full lock)
