2 Equipment Description
2.20 24 Vdc Fuse Protection
R688 HPM High-Performance Process Manager Service 115
December 2020 Honeywell
IOP Only Card File Fuse Protection
The following table lists the individual backpanel fuses and their application for the 15-Slot card file.
The fuse rating is 2 A for fuse locations F1 through F15.
Table 8 IOP Only Card File Fuse Protection
Fuse
Rating
Protection Application
F1
2 A fast-action/3 A time-delay
Slot 1 IOP card and associated FTA
F2
2 A fast-action/3 A time-delay
Slot 2 IOP card and associated FTA
F3
2 A fast-action/3 A time-delay
Slot 3 IOP card and associated FTA
F4
2 A fast-action/3 A time-delay
Slot 4 IOP card and associated FTA
F5
2 A fast-action/3 A time-delay
Slot 5 IOP card and associated FTA
F6
2 A fast-action/3 A time-delay
Slot 6 IOP card and associated FTA
F7
2 A fast-action/3 A time-delay
Slot 7 IOP card and associated FTA
F8
2 A fast-action/3 A time-delay
Slot 8 IOP card and associated FTA
F9
2 A fast-action/3 A time-delay
Slot 9 IOP card and associated FTA
F10
2 A fast-action/3 A time-delay
Slot 10 IOP card and associated FTA
F11
2 A fast-action/3 A time-delay
Slot 11 IOP card and associated FTA
F12
2 A fast-action/3 A time-delay
Slot 12 IOP card and associated FTA
F13
2 A fast-action/3 A time-delay
Slot 13 IOP card and associated FTA
F14
2 A fast-action/3 A time-delay
Slot 14 IOP card and associated FTA
F15
2 A fast-action/3 A time-delay
Slot 15 IOP card and associated FTA
F16
0.5 A fast-action
LLAI Optical Coupler Module, U1
