3 UCN Status Displays
3.7 HPMM Detail Status Displays
R688 HPM High-Performance Process Manager Service 257
December 2020 Honeywell
Data fields definitions
The display data fields are defined in the following table. Data is updated every 4 seconds.
Table 51 HPMM Node Status Information Display
The Hard failure condition that existed prior to the last
restart of the HPMM Control processor. The mnemonic
in this field serves as an entry to the Table 58 in the
“Fault Isolation” section.
The current Hard failure detected by the I/O Link
processor. The mnemonic in this field serves as an entry
to Table 58 in the “Fault Isolation” section.
The current Hard failure detected by the HPMM Control
processor. The mnemonic in this field serves as an entry
to Table 58 in the “Fault Isolation” section.
The current Hard failure detected by the HPMM
Communications processor. The mnemonic in this field
serves as an entry into Table 60 in the “Fault Isolation”
section.
The previous status of the HPMM Communications
processor. (ALIVE, IDLE, FAIL, OK, POWERON)
REDUN PARTNER UCN
VISIBILITY
The redundant HPMM’s visibility on the UCN (VISIBLE
or NOT VISIBLE).
REDUN PARTNER IOL
VISIBILITY
The redundant HPMM’s visibility on the I/O Link.
(VISIBLE or NOT VISIBLE).
A code that indicates the reason for the failure of the
HPMM load.
Hexadecimal data that shows the status of the load
operation.
The current load packet identifier
An integer that gives the address of the UCN node
performing the load.
Hexadecimal data that shows the state of the HPMM at
startup or failover.
