3.7 HPMM Detail Status Displays
244 HPM High-Performance Process Manager Service R688
Honeywell December 2020
Control Configuration display information
Control Configuration information is found in the following table.
Table 48 HPMM Control Configuration Display
Term
Description
SCANRATE
See the Process Operations Manual Section 18,
for the displayed states.
SEQPROC
See the Process Operations Manual, Section 18,
for the displayed states.
TOTAL SEQUENCE MEM
The TOTAL SEQUENCE MEMory available in
BLOCKS
CONFIG SEQUENCE MEM
The number of CONFIGuration SEQUENCE
MEMory BLOCKS in use
CONTROL SLOTS
Number of regulatory CONTROL SLOTS and
the number configured for FAST scan
PV SLOTS
The total number of regulatory PV SLOTS and
the number configured for FAST scan
LOGIC SLOTS
Total number of regulatory LOGIC SLOTS and
the number configured for FAST scan
DIGITAL COMPOSITES
The total number of regulatory DIGITAL
COMPOSITE slots and the number configured
for FAST scan
PROCESS MODULES
The total number of PROCESS MODULES
Note: The Process Module point with * indicates
that the point is processed twice a second.
ARRAY SLOTS
The total number of ARRAY SLOTS
DEVICE CTL SLOTS
The total number of regulatory DEVICE CTL
(Control) SLOTS and the number configured for
FAST scan
FLAGS
The total number of FLAGS
NUMERICS
The total number of NUMERICS
TIMERS
The total number of TIMERS
STRINGS
The total number of STRINGS
TIMES
The total number of TIMES
ARRAY/SI SCAN PERIOD
The ARRAY/SI (Serial Interface) SCAN PERIOD
in seconds
NUMBER SCAN TABLE ITEMS
The number of Scan table items
PEER TO PEER EFFICIENCY
The peer to peer efficiency in percentage.
PEER TO PEER SCAN PERIOD
The peer to peer scan period in seconds.
