3 UCN Status Displays
3.4 Display Operation
R688 HPM High-Performance Process Manager Service 205
December 2020 Honeywell
UCN Network Statistics display definitions
The information in the UCN Network Statistics display is defined in the following table.
Table 30 UCN Network Statistics Display Definitions
Term
Definition
ND
The node number.
TYP
The hardware type of node (NIM, LM, HPM, APM, or PM).
CBL
The active UCN cable (A or B).
A SIL
An asterisk indicates the node detected a silence event for
Cable A.
B SIL
An asterisk (*) indicates the node detected a silence event for
Cable B.
A NSY
An asterisk (*) indicates the node detected a noise event for
Cable A.
B NSY
An asterisk (*) indicates the node detected a noise event for
Cable B.
SWAP DIS
An asterisk (*) indicates that UCN cable auto-swap is disabled
(partial frame with missing start delimiter).
NOISE COUNT
The total number of times the node detected a noise event
(partial frame with missing end delimiter).
FRAME FRAGS
The total number of times the node detected frame fragments.
PASS RPTS
The total number of times the node retried a token pass to a
successor node.
CKSUM ERRS
The total number of times the node detected a checksum
error.
REPTR ERRS
The total number of times the node detected a repeater error.
AUTO RECON
The total number of times the node attempted auto reconnect.
TIME SYNCH
STATUS
The status of the node’s Time Synch. (INITIAL, FAILED,
SYNC FAILED, DEGRADED, LCN BAD, LCN OK, or OK).
