Honeywell HPM User Manual

4 Fault Isolation
4.3 Fault Isolation Concepts
R688 HPM High-Performance Process Manager Service 347
December 2020 Honeywell
Table 62 IOP Box Soft Failure Error Codes
Error
Code
Failure
Mnemonic
Description
Corrective Action
57
F2CAL_FL
FTA 2 calibration procedure failed.
Recalibrate the FTA.
58
LOSTSYNC
Secondary IOP has lost
synchronization.
If the primary IOP is in OK, resynch with the
START command. If the primary IOP is in IDLE,
resynch with the IDLE command.
59
WRITENBL
AO or DO IOP write enable failure.
Replace the IOP at the earliest convenience.
IOP failure can result in indeterminate outputs.
60
MLTINPFL
Multiple input failure detected.
Replace the IOP.
61
REDNDIAG
Redundancy diagnostic failure.
If an AO, replace the FTA’s plug-in module
after forcing IOP A to be the primary.
If an HLAI, replace the IOPs one at a time
following database synchronization.
62
Spare062
63
WRONG_H
W
Wrong hardware revision for IOP
redundancy
Replace the IOP with an IOP that supports
redundancy (proper hardware revision).
64
HWFIFOFL
The DISOE Hardware FIFO
diagnostic failed. The PVs of all
points are set to BAD.
Replace the IOP.
65
PRVRAMFL
The DISOE Private RAM diagnostic
failed. The PVs of all points are set to
BAD.
Replace the IOP.
66
SOECLKFL
The DISOE clock failed. The PVs of
all points are set to BAD.
Replace the IOP.
67
PVVALDFL
The PV validation diagnostic failed.
The PVs of all points are set to BAD.
Replace the IOP.
68
SOECNTFL
The DISOE SOE counter diagnostic
failed.
Replace the IOP.
69
DTPATHFL
Data path failure.
Replace the FTA when convenient.
70
DTPATHTO
Data path failure.
Replace the FTA when convenient.
71
STAMCHFL
The DISOE State Machine diagnostic
failed. The PVs of all points are set to
BAD.
Recalibrate the FTA.
72
to
255
Not used.
Not applicable.
