4 Fault Isolation
4.9 HPMM Alphanumeric Display
376 HPM High-Performance Process Manager Service R688
Honeywell December 2020
Sequence
Number
Label
Description
9D
Spare
9E
CTS_MTOS
Transitioning to MTOS
9F
to
A1
Spare
A2
CMS_PRGFLASH
Program the Flash ROM
A3
Spare
A4
Spare
A5
CMS_I OLD RT
I/O Link SRAM destructive pattern test
A6
Spare
A7
CMS_IOL_BWL
I/O Link SRAM B/W/L decode test
A8
Spare
A9
CMS_IOLCLRR
I/O Link SRAM initialization
AA
Spare
AB
CMS_IOLPCHK
I/O Link SRAM parity circuitry test
AC
Spare
AD
CMS_GB_PCHK
Global Bus parity circuitry test
AE
Spare
AF
CMS_EEPRMI
I/O Link Serial EEPROM access test
B0
Spare
B1
Spare
B2
CMS_IOL1 RST
Release I/O Link #1 from reset
B3
Spare
B4
CMS_IOL1 IDL
Transition I/O Link #1 to IDLE
B5
Spare
B6
Spare
B7
CMS_IOL1 RUN
Transition I/O Link #1 to RUN
B8
Spare
B9
CMS_IOL2RST
Release I/O Link #2 from reset
BA
Spare
BB
CMS_IOL2IDL
Transition I/O Link #2 to IDLE
BC
Spare
BD
CMS_IOL2RUN
Transition I/O Link #2 to RUN
BE
to
FA
Spare
FB
CMS_LR_BKUP
Backup the Local RAM to Global RAM
FC
Spare
FD
Spare
FE
CMS_MTOS
Transitioning to MTOS
FF
Spare
