Set this parameter to the authentication protocol set on the device.
The default selection is SHA.
Support SHA and MD5 agreement.
Set this parameter to the SHA or MD5 password set on the device.
Set this parameter to the privacy protocol set on the device. The
default selection is AES128.
Support CBC_DES, AES128, AES192, and AES256 agreement.
Set this parameter to the AES or DES password set on the device.
NOTE
You are advised to set Authentication Password and Privacy Password to
different values.
Timeout duration for connection test (set to 3s by default)
Step 8 Click Connection Test to start the connection test.
Step 9 After the connection test is successful, click in the toolbar to save the device
information.
----End
6.4.2 Adding Sensors
6.4.2.1 Adding Dry Contact Interface Devices
6.4.2.1.1 Setting Door Status Sensor Monitoring Parameters on the ECC
After connecting a door status sensor (DSS) to the AI/DI port of an ECC500 V6 collector, you
need to set DSS parameters on the web user interface (WebUI) of the collector.
Prerequisites
You have obtained the IP address, and login user name and password for the ECC500 V6
collector.
A PC with an IP address in the same network segment as the ECC500 V6 collector is
prepared, and the PC has been connected to the ECC500 V6 collector over a switch.
Context
This section describes how to set DSS monitoring parameters when a DSS is connected to the
AI/DI_1 port of the MUE05A4 card of an ECC500 V6 collector. Set the parameters based on
the actual port connected to the DSS onsite.
Procedure
Step 1 Log in to the WebUI of the ECC500 V6 collector.
