Huawei iManager NetEco 6000 User Manual

iManager NetEco 6000
Device Installation and Commissioning Guide
6 Adding Devices
Issue 03 (2019-03-10)
Copyright © Huawei Technologies Co., Ltd.
225
Context
The door access controller synchronized by the ECC800 to the NetEco does not support
formatting.
Procedure
Step 1 Choose Configuration > Configuration Management > Access Control Management
from the main menu. The Access Control Management window is displayed.
Step 2 In the Controllers tab page, click in the Operation list. The confirm dialog box is
displayed.
Step 3 Click Yes. The access controller is successfully formatted.

After formatting the access controller, click to initialize parameters. In this manner, the
timezones are enabled. The access controller is not disabled even if the parameters are not initialized
or the timezones are not enabled.

Synchronize the timezones and then the user groups or holidays after an access controller is
formatted and parameters are initialized.
----End
6.4.3.5 Setting Monitoring Parameters for the NEWABEL CHD200G
Fingerprint Controller
Context
This section applies to the settings of the card reader with a keypad, fingerprint and card
reader, and fingerprint and card reader with a keypad.
Procedure
Step 1 Set the baud rate of the NEWABEL CHD200G fingerprint controller to 9600 on the ECC500
collector. The preset address is 1. The address does not need to be set. When creating the
device on the NetEco, set Device Address to 1.
----End
6.4.3.6 Creating a NEWABEL CHD200G Fingerprint Controller on the
NetEco
Prerequisites

You have logged in to the NetEco client.

You have the operation rights for Data Center Planning.

You have created a management domain for the device to be added on the Data Center
Planning page.

You have created an access controller on the NetEco.
