iManager NetEco 6000
Device Installation and Commissioning Guide
Copyright © Huawei Technologies Co., Ltd.
Table 6-27 Mapping between Extended Info tab name and slot number of the AI/DI expansion
card
Extended Info Tab Name
on the NetEco
Slot Number of the
AI/DI Expansion Card
4. Change the dry contact counter name of the collector in the corresponding text box.
For example, if the independent deployment AI/DI unit is MUE06A1 and the dry contact
is connected through the AI/DI_1 port, modify the counter name in the
MUE06A1_AI_DI_1 text box. After a dry contact signal name is modified, the alarm
name corresponding to the dry contact signal is automatically modified.
5. Click to save the changes.
Modifying Alarm Names for Dry Contacts on the NetEco (for V1.2)
1. On the main menu, choose Alarm > Alarm Operation > Alarm Settings to go to the
Alarm Settings page.
2. In the navigation pane on the left, choose Custom Alarm > Redefine Alarm.
3. Click Create.
4. Click Select Alarm. In the displayed dialog box, select
Collector_HUAWEI_ECC500V6_SNMP for Device Type on the left, select the alarm
name to be modified on the right, and click OK.
5. Specify New Alarm Name, Alarm Type, and Alarm Severity, and click Next.
6. Select an applicable scope.
The alarm name modification applies to all ECC500 V6 devices in the
data center.
The alarm name modification applies to the ECC500 V6 devices in the
selected management domain.
6.4.2.1.7 Modifying Performance Counters for Dry Contacts on the NetEco
Prerequisites
You have logged in to the NetEco client.
You have the operation rights for Data Center Planning.
You have created an ECC500 collector in the Date Center Planning page.
