Huawei iManager NetEco 6000 User Manual

iManager NetEco 6000
Device Installation and Commissioning Guide
6 Adding Devices
Issue 03 (2019-03-10)
Copyright © Huawei Technologies Co., Ltd.
222
----End
6.4.3 Adding the Access Management System
6.4.3.1 Setting Monitoring Parameters for the A8802RS or A8804RS Access
Controller
Procedure
Step 1 Set the address of the access controller using the DIP toggle switches, as shown in Table 6-34.
Table 6-34 Setting the address of the access controller
Address Value
Toggle switch 1
Toggle switch 2
0
OFF
OFF
1
ON
OFF
2
OFF
ON
3
ON
ON
Step 2 Set the baud rate of the access controller to 19200. The preset data bit, stop bit, and check bit
are 8, 1, and none respectively.
For ECC collector settings, see 6.4.1.4 Setting RS485 Parameters for the ECC500 V6
Collector.
----End
6.4.3.2 Setting Monitoring Parameters for the Shengjiu_MS899 Electronic
Door Lock
The Shengjiu MS899 electronic door lock supports a maximum of 16 users.
1. The address of the MS899 electronic door lock is 1, when creating an MS899 on the
NetEco, set Device address to the same value.
2. Set the baud rate of the access controller to 9600. The preset data bit, stop bit, and check
bit are 8, 1, and none respectively.
For ECC collector settings, see Setting RS485 Parameters for the ECC500 V6
Collector.
6.4.3.3 Creating an A8802RS/A8804RS Access Controller on the NetEco
Prerequisites

You have logged in to the NetEco client.

You have the operation rights for Access Control Management and Data Center
Planning.
