Conguraon examples
Detailed conguraon examples can be found in the following subchapters:
4Example 1: Input range 10 ... 85 kHz ≡ seng range 0 ... 50 Hz ^ 569
4Example 2: Input range 10 ... 85 kHz ≡ seng range -50 ... 50 Hz ^ 569
Parameter Name / value range / [default seng] Info
0x2631:022
(P400.22)
Funcon list: Acvate setpoint via HTL input
(Funcon list: Setp: HTL input)
•
For further possible sengs, see parameter
0x2631:001 (P400.01). ^ 532
Assignment of a trigger for the "Acvate setpoint via HTL input" func-
on.
Trigger = TRUE: HTL input is used as setpoint source (if the trigger
assigned has the highest setpoint priority).
Trigger = FALSE: no acon / deacvate funcon again.
0 Not connected
0x2640:001
(P415.01)
HTL input sengs: Minimum frequency
(HTL inp. seng: Min.frequency)
-100000.0 ... [0.0] ... 100000.0 Hz
•
From version 04.00
Denion of the input range of the HTL input.
0x2640:002
(P415.02)
HTL input sengs: Maximum frequency
(HTL inp. seng: Max. frequency)
-100000.0 ... [0.0] ... 100000.0 Hz
•
From version 04.00
0x2640:003
(P415.03)
HTL input sengs: Minimum motor frequency
(HTL inp. seng: Min.motor.freq)
-1000.0 ... [0.0] ... 1000.0 Hz
•
From version 04.00
Denion of the seng range for operang mode "MS: Velocity mode".
•
Direcon of rotaon according to sign.
•
The standard setpoint source for operang mode 0x6060 (P301.00) =
"MS: Velocity mode [-2]" is selected in 0x2860:001 (P201.01).
0x2640:004
(P415.04)
HTL input sengs: Maximum motor frequency
(HTL inp. seng: Max.motor.freq)
Device for 50-Hz mains: -1000.0 ... [50.0] ... 1000.0 Hz
Device for 60-Hz mains: -1000.0 ... [60.0] ... 1000.0 Hz
•
From version 04.00
0x2640:005
(P415.05)
HTL input sengs: Minimum PID setpoint
(HTL inp. seng: Min.PID setpoint)
-300.00 ... [0.00] ... 300.00 PID unit
•
From version 04.00
Denion of the seng range for PID control.
•
The standard setpoint source for the reference value of PID control is
selected in 0x2860:002 (P201.02).
0x2640:006
(P415.06)
HTL input sengs: Maximum PID setpoint
(HTL inp. seng: Max.PID setpoint)
-300.00 ... [100.00] ... 300.00 PID unit
•
From version 04.00
0x2640:007
(P415.07)
HTL input sengs: Minimum torque setpoint
(HTL inp. seng: Min.torque setp.)
-400.0 ... [0.0] ... 400.0 %
•
From version 04.00
Denion of the seng range for operang mode "MS: Torque mode".
•
100 % ≡ Motor rated torque 0x6076 (P325.00)
•
Direcon of rotaon according to sign.
•
The standard setpoint source for operang mode 0x6060 (P301.00) =
"MS: Torque mode [-1]" is selected in 0x2860:003 (P201.03).
4Torque control w/ freq. limit ^ 206
0x2640:008
(P415.08)
HTL input sengs: Maximum torque setpoint
(HTL inp. seng: Max.torque setp)
-400.0 ... [100.0] ... 400.0 %
•
From version 04.00
0x2640:009
(P415.09)
HTL input sengs: Filter me constant
(HTL inp. seng: Filter me)
0 ... [10] ... 10000 ms
•
From version 04.00
PT1 me constant for low-pass lter.
0x2641:001
(P416.01)
HTL input monitoring: Minimum frequency threshold
(HTL inp. monit.: Min.freq.thresh.)
-214748364.8 ... [0.0] ... 214748364.7 Hz
•
From version 04.00
Sengs for monitoring the HTL input.
0x2641:002
(P416.02)
HTL input monitoring: Minimum delay threshold
(HTL inp. monit.: Min.delay thres.)
0.0 ... [5.0] ... 300.0 s
•
From version 04.00
0x2641:003
(P416.03)
HTL input monitoring: Maximum frequency threshold
(HTL inp. monit.: Max.freq.thresh.)
-214748364.8 ... [0.0] ... 214748364.7 Hz
•
From version 04.00
0x2641:004
(P416.04)
HTL input monitoring: Maximum delay threshold
(HTL inp. monit.: Max.delay thres.)
0.0 ... [5.0] ... 300.0 s
•
From version 04.00
Flexible I/O conguraon
Setpoint change-over
HTL input setpoint source
567
