IF THE IGNITION SYSTEM FAILS TO OPERATE
Procedure
Check:
1. Fuse (Main) 7.Pickup coil resistance
2. Battery 8.Main switch
3. Spark plug 9.Engine stop switch
4. lgnition spark gap 10.Wiring connection
5. Spark plug cap resistance (entire ignition system)
6. Ignition coil
1.Fuse NO CONTINUITY
Check switches
Replace the fuse.
CONTINUITY
2. Battery INCORRECT
z Clean battery terminals.
z Recharge or replace the battery.
z Check the battery condition.
Refer to "BATTERY
INSPECTION"
CORRECT
Standard spark plug: DR8EA / NGK
3.Spark plug
OUT OF SPECIFICATION
Repair or replace the spark plug
z Check the spark plug
condition.
z Check the spark plug
type.
z Check the spark plug gap.
Spark plug gap: 0.6 ～
0.7mm
*
To Next Page
