CHAPTER 3A ENGINE 260/ 300 / 400 cc ATV SERVICE MANUAL09.0
CHAPTER 3 ENGINE PAGE. 3A- 42
PRIMARY SHEAVE
*Apply molybdenum disulfide grease
Order Job name / Part name Q ’ty Remarks
V-belt, clutch and secondar
y
/ Remove the
p
arts in orde
r
1
primary sheave removal
Nut/Plain washe
r
1/1
Refer to "PRIMARY SHEA VE
2
Primar
y
fixed sheave
1
REMOVAL" section.
3
Nut
1
Refer to "SECONDARY SHEAVE
4
Clutch housin
g
1
A
ND V-BELT REMOVAL"
5
Clutch assembl
y
1
section.
6
V-belt
1
Refe
r
to "SECONDARY SHEAVE
7
Primar
y
slidin
g
sheave
1
INSTALLATION" section.
8 Colla
r
1
9
Primar
y
sheave ca
p
1
Refer to "PRIMARY SHEAVE
10
Cam
1
A
SSEMBLY" section.
11
Wei
g
ht
8
12
Slider 4 Refer to "PRIMARY SHEAVE
13
S
p
ace
r
4 ASSEMBLY" section.
14 Oil seal 1 Reverse the removal
Procedure for installation.
