CHAPTER 3A
ENGINE
260/
300
/
400
cc
A
TV
SERVICE
MANUAL09.0
CHAPTER
3
ENGINE P
AGE.
3A-
55
3.9OIL
PUMP
Order
Job name/ Part name
Q'ty
Remarks
Oil pump
removal
Remove the
p
ar
t
s in order
.
A.C. magneto
R
efer to "A.C.
MA
GNET
O AND
ST
ARTER
1 Cover
1
CLUTCH"
section.
2 Pum
p
driven
g
ea
r
1
3 Dowel
pin
1
4 Oil
pump
assembly
1
5 Gasket
1
6
Impeller shaft gear
1
7 Dowel
Pin
1
8 Shaft
1
Reverse the removal procedure for
installation.
