TROUBLESHOOTING
IF THE STARTER MOTOR FAILS TO OPERATE
Procedure
Check:
1. Fuse (Main)
2. Battery
3. starter motor
4. starter relay
5. starting circuit cut-off relay
6. main switch
7. Engine stop switch
8. front/rear brake switch
9. starter switch
10. wiring connection (entire starting system)
1. fuse
refer to “CHECKING SWITCHES”
section
NO CONTINUITY
Replace the fuse
2. Battery
Check the battery condition.
Refer to "BATTERY INSPECTION" section
in CHAPTER 3
INCORRECT
Clean battery terminals
Recharge or replace the battery
3. Starter motor
Connect the battery positive terminal
and starter motor cable using a jumper
lead.
Check the starter motor operation
DOES NOT MOVE
Repair or replace the starter
motor
To Next Page
