CHAPTER 3A ENGINE 260/ 300 / 400 cc ATV SERVICE MANUAL09.0
CHAPTER 3 ENGINE PAGE. 3A- 35
3.6CYLINDER AND PISTON
Order Job name / Part name Q ’ty Remarks
Cylinder and piston removal Remove the parts in order.
C
y
linder head Refer to " CYLINDER HEAD "
1
Joint
1
section .
2
O-rin
g
2
3
Timing chain guide (exhaust side) 1
Refer to " PISTON RINGS
,
4
Cylinder 1
PISTON AND CYLINDER
INSTALLATION" section.
5
Dowel
p
in 2
6
C
y
linder
g
asket 1
7
Piston
p
in circli
p
2 Refer to "PISTON AND
8
Piston
p
in 1
PISTON RINGS REMOVAL
"
9
Piston 1
section .
10
Piston ring (top)
1 Refer to "PISTON RINGS,
11
Piston ring (2nd)
1 PISTON AND CYLINDER
12 Side rail/Spacer 2/1 INSTALLATION " section .
Reverse the removal
procedure for installation .
