Technical Information
18
DGC 6xxx
Figure 010-3: Right Side Panel Removal
4.4 Rear/Left Side Panel Removal
Note:
The left side panel is combined with the rear panel.
1. Remove the appliance from its housing unit; see Section 010-4.1.
2. Disconnect the appliance from the power supply.
3. Remove the lid; see Section 010-4.2.
4. Remove the five T20 screws securing the left side panel, as well as the
four T20 screws securing the rear panel; see Figure 010-4, Item 1.
5. Remove the rear/left side panel.
