Technical Information
92
DGC 6xxx
060 Control Panel
2 Function
2.1 Optical Interface
The appliance has an optical interface for diagnostic support or program
updating; see Figure D-1. It can be located with the "Find optical interface"
function of the Miele diagnostic utility.
2.2 M-Touch Display (Model-Dependent)
Figure 060-1: M-Touch Display
1 Navigation strip
2 Control panel
3 Status strip
4 Menu tree
5 Clock
6 OK touchpad field
7 Navigation area
8 Touchpad area
Some models feature an M-touch display. The appliance is operated via the
touch-sensitive surface of the display and by touchpads on the fascia panel.
The M-touch display is activated when it is pressed with the fingertips, which
generates a tiny electrical charge and thus an electrical impulse that is
detected by the M-touch display's touchscreen.
Note:
The M-touch display may not respond to cold fingers.
The M-touch display will not respond when touched by objects (pens, etc.).
